# Deep Reinforcement Learning – Winter 2018/19

In recent years, reinforcement learning has been combined with deep neural networks, giving rise to game agents with super-human performance (for example for Go, chess, or 1v1 Dota2, capable of being trained solely by self-play), datacenter cooling algorithms being 50% more efficient than trained human operators, or improved machine translation. The goal of the course is to introduce reinforcement learning employing deep neural networks, focusing both on the theory and on practical implementations.

Python programming skills and TensorFlow skills (or any other deep learning framework) are required, to the extent of the NPFL114 course. No previous knowledge of reinforcement learning is necessary.

SIS code: NPFL122
Semester: winter
E-credits: 6
Examination: 2/2 C+Ex
Guarantor: Milan Straka

### Timespace Coordinates

• lecture: the lecture is held on Monday 12:20 in S3; first lecture is on Oct 08
• practicals: there are two parallel practicals, on Tuesday 9:00 in SU1 and on Tuesday 10:40 in SU1; first practicals are on Oct 09

### Requirements

To pass the practicals, you need to complete at least 80% of compulsory home assignments. Several additional voluntary assignments will be available, and up to 40 points from these will be transfered to the exam.

To pass the exam, you need to obtain at least 60, 75 and 90 out of 100 points for the written exam (plus up to 40 points from the practicals), to obtain grades 3, 2 and 1, respectively.

The lecture content, including references to study materials.

The main study material is the Reinforcement Learning: An Introduction; second edition by Richard S. Sutton and Andrew G. Barto (reffered to as RLB). It is available online and also as a hardcopy since October 15, 2018.

References to study materials cover all theory required at the exam, and sometimes even more – the references in italics cover topics not required for the exam.

### 1. Introduction to Reinforcement Learning

• History of RL [Chapter 1 of RLB]
• Multi-armed bandits [Chapter 2 of RLB]

### 2. Markov Decision Process, Optimal Solutions, Monte Carlo Methods

• Markov Decision Process [Sections 3-3.3 of RLB]
• Policies and Value Functions [Sections 3.5-3.6 of RLB]
• Value Iteration [Sections 4 and 4.4 of RLB]
• Proof of convergence only in slides
• Policy Iteration [Sections 4.1-4.3 of RLB]
• Generalized Policy Iteration [Section 4.6 or RLB]
• Monte Carlo Methods [Sections 5-5.4 of RLB]

### 3. Temporal Difference Methods, Off-Policy Methods

• Model-free and model-based methods, using state-value or action-value functions [Chapter 8 before Section 8.1, and Section 6.8 of RLB]
• Temporal-difference methods [Sections 6-6.3 of RLB]
• Sarsa [Section 6.4 of RLB]
• Q-learning [Section 6.5 of RLB]
• Off-policy Monte Carlo Methods [Sections 5.5-5.7 of RLB]
• Expected Sarsa [Section 6.6 of RLB]

### 4. N-step Methods, Function Approximation

• Double Q-learning [Section 6.7 of RLB]
• N-step TD policy evaluation [Section 7.1 of RLB]
• Off-policy n-step Sarsa [Section 7.3 of RLB]
• Tree backup algorithm [Section 7.5 of RLB]
• Function approximation [Sections 9-9.3 of RLB]
• Tile coding [Section 9.5.4 of RLB]

### 6. Rainbow

• Policy Gradient Methods [Sections 13-13.1 of RLB]
• Policy Gradient Theorem [Section 13.2 of RLB]
• REINFORCE algorithm [Section 13.3 of RLB]
• REINFORCE with baseline algorithm [Section 13.4 of RLB]
• Actor-Critic methods [Section 13.5 of RLB, without the eligibility traces variant]

### 11. V-trace, PopArt Normalization, Partially Observable MDPs

You should submit the assignments in the ReCodEx Code Examiner, where they will be either automatically or manually evaluated (depending on the assignment). The evaluation is performed using Python 3.6, TensorFlow 1.11.0, NumPy 1.15.2 and OpenAI Gym 0.9.5. For those using PyTorch, CPU version 1.0.0 is available.

You can install TensorFlow and Gym either to user packages using pip3 install --user tensorflow==1.11.0 gym==0.9.5 scipy box2d-py atari-py (with the last three backages being optinal dependencies of gym), or create a virtual environment using python3 -m venv VENV_DIR and then installing the packages inside it by running VENV_DIR/bin/pip3 install tensorflow==1.11.0 gym==0.9.5 scipy box2d-py atari-py. On Windows, you can use third-party precompiled versions of box2d-py and atari-py. Note that when your CPU does not support AVX, you need to install TensorFlow 1.5.

### Submitting Data Files to ReCodEx

Even if ReCodEx allows submitting data files beside Python sources, the data files are not available during evaluation. Therefore, in order to submit models, you need to embed them in Python sources. You can use the embed.py script, which compressed and embeds given files and directories into a Python module providing an extract() method.

### Teamwork

Working in teams of size 2 (or at most 3) is encouraged. All members of the team must submit in ReCodEx individually, but can have exactly the same sources/models/results. However, each such solution must explicitly list all members of the team to allow plagiarism detection using this template.

### multiarmed_bandits

Perform a parameter study of various approaches to solving multiarmed bandits. For every hyperparameter choice, perform 1000 episodes, each consisting of 1000 trials, and report averaged return (a single number).

Start with the multiarmed_bandits.py template, which defines MultiArmedBandits environment. We use API based on OpenAI Gym Environment class, notably the following two methods:

• reset() → new_state: starts a new episode
• step(action) → new_state, reward, done, info: perform the chosen action in the environment, returning the new state, obtained reward, a boolean flag indicating an end of episode, and additional environment-specific information Of course, the states are not used by the multiarmed bandits (None is returned).

Your goal is to implement the following modes of calculation. For each mode evaluate the performance given specified hyperparameters and plot the results for all modes together in a single graph.

• greedy: perform $ε$-greedy search with parameter epsilon, computing the value function using averaging. Plot results for $ε ∈ \{1/64, 1/32, 1/16, 1/8, 1/4\}$.
• greedy and alpha$≠0$: perform $ε$-greedy search with parameter epsilon and initial function estimate of 0, using fixed learning rate alpha. Plot results for $α=0.15$ and $ε ∈ \{1/64, 1/32, 1/16, 1/8, 1/4\}$
• greedy, alpha$≠0$ and initial$≠0$: perform $ε$-greedy search with parameter epsilon, given initial value as starting value function and fixed learning rate alpha. Plot results for initial$=1$, $α=0.15$ and $ε ∈ \{1/128, 1/64, 1/32, 1/16\}$.
• ucb: perform UCB search with confidence level c and computing the value function using averaging. Plot results for $c ∈ \{1/4, 1/2, 1, 2, 4\}$.
• gradient: choose actions according to softmax distribution, updating the parameters using SGD to maximize expected reward. Plot results for $α ∈ \{1/16, 1/8, 1/4, 1/2\}$.

This task will be evaluated manually and you should submit the Python source and the generated graph.

### policy_iteration

Consider the following gridworld:

Start with policy_iteration.py, which implements the gridworld mechanics, by providing the following methods:

• GridWorld.states: return number of states (11)
• GridWorld.actions: return lists with labels of the actions (["↑", "→", "↓", "←"])
• GridWorld.step(state, action): return possible outcomes of performing the action in a given state, as a list of triples containing
• probability: probability of the outcome
• reward: reward of the outcome
• new_state: new state of the outcome

Implement policy iteration algorithm, with --steps steps of policy evaluation/policy improvement. During policy evaluation, use the current value function and perform --iterations applications of the Bellman equation. Perform the policy evaluation synchronously (i.e., do not overwrite the current value function when computing its improvement). Assume the initial policy is “go North” and initial value function is zero.

After given number of steps and iterations, print the resulting value function and resulting policy. For example, the output after 4 steps and 4 iterations should be:

    9.15→   10.30→   11.32→   12.33↑
8.12↑             3.35←    2.58←
6.95↑    5.90←    4.66←   -4.93↓


### monte_carlo

Solve the CartPole-v1 environment environment from the OpenAI Gym using the Monte Carlo reinforcement learning algorithm.

Use the supplied cart_pole_evaluator.py module (depending on gym_evaluator.py) to interact with the discretized environment. The environment has the following methods and properties:

• states: number of states of the environment
• actions: number of actions of the environment
• episode: number of the current episode (zero-based)
• reset(start_evaluate=False) → new_state: starts a new episode
• step(action) → new_state, reward, done, info: perform the chosen action in the environment, returning the new state, obtained reward, a boolean flag indicating an end of episode, and additional environment-specific information
• render(): render current environment state

Once you finish training (which you indicate by passing start_evaluate=True to reset), your goal is to reach an average return of 490 during 100 evaluation episodes. Note that the environment prints your 100-episode average return each 10 episodes even during training.

You can start with the monte_carlo.py template, which parses several useful parameters, creates the environment and illustrates the overall usage.

During evaluation in ReCodEx, three different random seeds will be employed, and you need to reach the required return on all of them. Time limit for each test is 5 minutes.

### q_learning

Solve the MountainCar-v0 environment environment from the OpenAI Gym using the Q-learning reinforcement learning algorithm. Note that this task does not require TensorFlow.

Use the supplied mountain_car_evaluator.py module (depending on gym_evaluator.py) to interact with the discretized environment. The environment methods and properties are described in the monte_carlo assignment. Your goal is to reach an average reward of -150 during 100 evaluation episodes.

You can start with the q_learning.py template, which parses several useful parameters, creates the environment and illustrates the overall usage. Note that setting hyperparameters of Q-learning is a bit tricky – I usualy start with a larger value of $ε$ (like 0.2 or even 0.5) an then gradually decrease it to almost zero.

During evaluation in ReCodEx, three different random seeds will be employed, and you need to reach the required return on all of them. The time limit for each test is 5 minutes.

### importance_sampling

Using the FrozenLake-v0 environment environment, implement Monte Carlo weighted importance sampling to estimate state value function $V$ of target policy, which uniformly chooses either action 1 (down) or action 2 (right), utilizing behaviour policy, which uniformly chooses among all four actions.

Start with the importance_sampling.py template, which creates the environment and generates episodes according to behaviour policy.

For $1000$ episodes, the output of your program should be the following:

 0.00  0.00  0.00  0.00
0.00  0.00  0.00  0.00
0.00  0.00  0.21  0.00
0.00  0.00  0.45  0.00


### lunar_lander

Deadline: Nov 11, 23:59  compulsory & 7 bonus

Solve the LunarLander-v2 environment environment from the OpenAI Gym. Note that this task does not require TensorFlow.

Use the supplied lunar_lander_evaluator.py module (depending on gym_evaluator.py to interact with the discretized environment. The environment methods and properties are described in the monte_carlo assignment, but include one additional method:

• expert_trajectory() → initial_state, trajectory This method generates one expert trajectory and returns a pair of initial_state and trajectory, where trajectory is a list of the tripples (action, reward, next_state). You can use this method only during training, not during evaluation.

To pass the task, you need to reach an average return of 0 during 100 evaluation episodes. During evaluation in ReCodEx, three different random seeds will be employed, and you need to reach the required return on all of them. Time limit for each test is 5 minutes.

The task is additionally a competition and at most 7 points will be awarded according to relative ordering of your solution performances.

You can start with the lunar_lander.py template, which parses several useful parameters, creates the environment and illustrates the overall usage.

### q_learning_tiles

Improve the q_learning task performance on the MountainCar-v0 environment environment using linear function approximation with tile coding. Your goal is to reach an average reward of -110 during 100 evaluation episodes.

Use the updated mountain_car_evaluator.py module (depending on updated gym_evaluator.py) to interact with the discretized environment. The environment methods and properties are described in the monte_carlo assignment, with the following changes:

• The env.weights method return the number of weights of the linear function approximation.

• The state returned by the env.step method is a list containing weight indices of the current state (i.e., the feature vector of the state consists of zeros and ones, and only the indices of the ones are returned). The (action-)value function for a state is therefore approximated as a sum of the weights whose indices are returned by env.step.

The default number of tiles in tile encoding (i.e., the size of the list with weight indices) is args.tiles=8, but you can use any number you want (but the assignment is solvable with 8).

You can start with the q_learning_tiles.py template, which parses several useful parameters, creates the environment and illustrates the overall usage. Implementing Q-learning is enough to pass the assignment, even if both N-step Sarsa and Tree Backup converge a little faster.

During evaluation in ReCodEx, three different random seeds will be employed, and you need to reach the required return on all of them. The time limit for each test is 5 minutes.

### q_network

Solve the CartPole-v1 environment environment from the OpenAI Gym using Q-learning with neural network as a function approximation.

The supplied cart_pole_evaluator.py module (depending on gym_evaluator.py) can also create a continuous environment using environment(discrete=False). The continuous environment is very similar to the discrete environment, except that the states are vectors of real-valued observations with shape environment.state_shape.

Use Q-learning with neural network as a function approximation, which for a given states returns state-action values for all actions. You can use any network architecture, but two hidden layers of 20 ReLU units are a good start.

Your goal is to reach an average return of 400 during 100 evaluation episodes.

You can start with the q_network.py template, which provides a simple network implementation in TensorFlow.

During evaluation in ReCodEx, two different random seeds will be employed, and you need to reach the required return on all of them. Time limit for each test is 10 minutes (so you can train in ReCodEx, but you can also pretrain your network if you like).

### car_racing

Deadline: Dec 2, 23:59  10 bonus only

Nov 27: The evaluator has been returning a reference to the same numpy array with the state, which could have caused problems if you did not create a copy (when stacking images or resizing it). It has now been fixed.

In this bonus-only exercise to play with Deep Q Network and its variants, try solving the CarRacing-v0 environment environment from the OpenAI Gym.

Use the supplied car_racing_evaluator.py module (depending on gym_evaluator.py to interact with the environment. The environment is continuous and states are RGB images of size $96×96×3$, but you can downsample them even more. The actions are also continuous and consist of an array with the following three elements:

• steer in range [-1, 1]
• gas in range [0, 1]
• brake in range [0, 1]

Internally you should generate discrete actions and convert them to the required representation before the step call. Good initial action space is to use 9 actions – a Cartesian product of 3 steering actions (left/right/none) and 3 driving actions (gas/brake/none).

The environment supports frame skipping without rendering the skipped frames – the second argument to env.step determines how many time is the given action repeated.

The task is a competition and at most 10 points will be awarded according to relative ordering of your solution performances. In ReCodEx, your solution is evaluated on 15 different tracks with a total time limit of 15 minutes. If your average return is at least 100, ReCodEx shows the solution as correct.

The car_racing.py template parses several useful parameters and creates the environment. Note that the car_racing_evaluator.py can be executed directly and in that case you can drive the car using arrows.

### reinforce

Solve the CartPole-v1 environment environment from the OpenAI Gym using the REINFORCE algorithm.

The supplied cart_pole_evaluator.py module (depending on gym_evaluator.py) can create a continuous environment using environment(discrete=False). The continuous environment is very similar to the discrete environment, except that the states are vectors of real-valued observations with shape environment.state_shape.

Your goal is to reach an average return of 490 during 100 evaluation episodes.

You can start with the reinforce.py template, which provides a simple network implementation in TensorFlow.

During evaluation in ReCodEx, two different random seeds will be employed, and you need to reach the required return on all of them. Time limit for each test is 5 minutes.

### reinforce_with_baseline

This is a continuation of reinforce assignment.

Using the reinforce_with_baseline.py template, solve the CartPole-v1 environment environment using the REINFORCE with baseline algorithm.

Using a baseline lowers the variance of the value function gradient estimator, which allows faster training and decreases sensitivity to hyperparameter values. To reflect this effect in ReCodEx, note that the evaluation phase will automatically start after 200 episodes. Using only 200 episodes for training in this setting is probably too little for the REINFORCE algorithm, but suffices for the variant with a baseline.

Your goal is to reach an average return of 490 during 100 evaluation episodes.

During evaluation in ReCodEx, two different random seeds will be employed, and you need to reach the required return on all of them. Time limit for each test is 5 minutes.

### cart_pole_pixels

Deadline: Dec 09, 23:59  compulsory & 7 bonus

The supplied cart_pole_pixels_evaluator.py module (depending on gym_evaluator.py) generates a pixel representation of the CartPole environment as an $80×80$ image with three channels, with each channel representing one time step (i.e., the current observation and the two previous ones).

To pass the compulsory part of the assignment, you need to reach an average return of 50 during 100 evaluation episodes. During evaluation in ReCodEx, two different random seeds will be employed, and you need to reach the required return on all of them. Time limit for each test is 10 minutes.

The task is additionally a competition and at most 7 points will be awarded according to relative ordering of your solution performances.

The cart_pole_pixels.py template parses several parameters, creates the environment and shows how to save and load neural networks in TensorFlow. To upload the trained model to ReCodEx, you need to embed the trained model files using embed.py, submit the resulting embedded_data.py along your solution, and in your solution you need to import embedded_data and then embedded_data.extract() (the template does this for you).

### paac

Using the paac.py template, solve the CartPole-v1 environment environment using parallel actor-critic algorithm.

The gym_environment now provides the following two methods:

• parallel_init(num_workers) → initial_states, which initializes the given number of parallel workers and returns their environment initial states. This method can be called at most once.
• parallel_step(actions) → List[next_state, reward, done, info], which performs given action in respective environment, and return the usual information with one exception: If done=True, then next_state is already a new state of newly started episode.

Your goal is to reach an average return of 450 during 100 evaluation episodes.

During evaluation in ReCodEx, two different random seeds will be employed, and you need to reach the required return on all of them. Time limit for each test is 10 minutes.

### paac_continuous

Using the paac_continuous.py template, solve the MountainCarContinuous-v0 environment environment using parallel actor-critic algorithm with continuous actions.

The gym_environment now provides two additional methods:

• action_shape: returns required shape of continuous action. You can assume the actions are always an one-dimensional vector.
• action_ranges: returns a pair of vectors low, high. These denote valid ranges for the actions, so low[i]$≤$action[i]$≤$high[i].

Your goal is to reach an average return of 90 during 100 evaluation episodes.

During evaluation in ReCodEx, two different random seeds will be employed, and you need to reach the required return on all of them. Time limit for each test is 10 minutes.

### ddpg

Using the ddpg.py template, solve the Pendulum-v0 environment environment using deep deterministic policy gradient algorithm.

To create the evaluator, use gym_evaluator.py.GymEvaluator("Pendulum-v0"). The environment is continuous, states and actions are described at OpenAI Gym Wiki.

Your goal is to reach an average return of -200 during 100 evaluation episodes.

During evaluation in ReCodEx, two different random seeds will be employed, and you need to reach the required return on all of them. Time limit for each test is 10 minutes.

### walker

Deadline: Jan 06, 23:59  10 bonus only

In this bonus-only exercise exploring continuous robot control, try solving the BipedalWalker-v2 environment environment from the OpenAI Gym.

To create the evaluator, use gym_evaluator.py.GymEvaluator("BipedalWalker-v2"). The environment is continuous, states and actions are described at OpenAI Gym Wiki.

The task is a competition and at most 10 points will be awarded according to relative ordering of your solution performances. In ReCodEx, your solution will be evaluated on 100 different tracks with a total time limit of 10 minutes. If your average return is at least 0, ReCodEx shows the solution as correct.

You can start with the ddpg.py template, only set args.env to BipedalWalker-v2.

### walker_hardcore

Deadline: Jan 06, 23:59  5 bonus only

As an extesnion of the walker assignment, try solving the BipedalWalkerHardcore-v2 environment environment from the OpenAI Gym.

The task is a competition and at most 5 points will be awarded according to relative ordering of your solution performances. In ReCodEx, your solution will be evaluated on 100 different tracks with a total time limit of 10 minutes. If your average return is at least 0, ReCodEx shows the solution as correct.

You can start with the ddpg.py template, only set args.env to BipedalWalkerHardcore-v2.

### az_quiz

Deadline: Jan 13, 23:59  10 bonus only

In this bonus-only exercise, use Monte Carlo Tree Search to learn an agent for a simplified version of AZ-kvíz. In our version, the agent does not have to answer questions and we assume that all answers are correct.

The game itself is implemented in the az_quiz.py module, using randomized=False constructor argument.

The evaluation in ReCodEx should be implemented by importing a module az_quiz_evaluator_recodex and calling its evaluate function. The argument this functions is an object providing a method play which given an AZ-kvíz instance returns the chosen move. The illustration of the interface is in the az_quiz_evaluator_recodex.py module.

Your solution in ReCodEx is automatically evaluated only against a random player az_quiz_player_random.py and a very simple heuristic az_quiz_player_simple_heuristic.py, playing against each of them 10 games as a starting player and 10 games as a non-starting player. The time limit for the games is 10 minutes and you should see win rate directly in ReCodEx. The final evaluation will be performed after the deadline by a round-robin tournament, utilizing your latest submission with non-zero win rate.

For inspiration, use the official pseudocode for AlphaZero.

### az_quiz_randomized

Deadline: Jan 13, 23:59  5 bonus only

Extend the az_quiz assignment to handle the possibility of wrong answers. Therefore, when choosing a field, the agent might answer incorrectly.

To instantiate this randomized game variant, pass randomized=True to the AZQuiz class of az_quiz.py.

The Monte Carlo Tree Search has to be slightly modified to handle stochastic MDP. The information about distribution of possible next states is provided by the AZQuiz.all_moves method, which returns a list of (probability, az_quiz_instance) next states (in our environment, there are always two possible next states).

The evaluation in ReCodEx should be implemented by importing a module az_quiz_evaluator_recodex and calling its evaluate function. The argument this functions is an object providing a method play which given an AZ-kvíz instance returns the chosen move. The illustration of the interface is in the az_quiz_evaluator_recodex.py module.

Your solution in ReCodEx is automatically evaluated only against a random player az_quiz_player_random.py and a very simple heuristic az_quiz_player_simple_heuristic.py, playing against each of them 10 games as a starting player and 10 games as a non-starting player. The time limit for the games is 10 minutes and you should see win rate directly in ReCodEx. The final evaluation will be performed after the deadline by a round-robin tournament, utilizing your latest submission with non-zero win rate.

For inspiration, use the official pseudocode for AlphaZero.

### vtrace

Using the vtrace.py template, implement the V-trace algorithm.

The template uses the CartPole-v1 environment and a replay buffer to more thoroughly test the off-policy capability of the V-trace algorithm.

However, the evaluation in ReCodEx will be performed by calling only the vtrace method and comparing its results to a reference implementation. Several values of hyperparameters will be used, each test has a time limit of 1 minute, and all tests must pass.

### memory_game

Deadline: Feb 17, 23:59  5 bonus only

In this bonus-only exercise we explore a partially observable environment. Consider a one-player variant of a memory game (pexeso), where a player repeatedly flip cards. If the player flips two cards with the same symbol in succession, the cards are removed and the player recieves a reward of +2. Otherwise the player recieves a reward of -1. An episode ends when all cards are removed. For a given even $N$, there are $N$ actions – the card indices, and $N/2$ observations, which encode card symbol. Every episode can be ended using at most $3N/2$ actions. The environment is provided by the memory_game_evaluator.py module.

Your goal is to solve the environment using an agent utilizing a LSTM cell. The reinforce algorithm with baseline seems an appropriate choice.

ReCodEx evaluates your solution on environments with 4, 6, 8 and 16 cards (utilizing the --cards argument). For each card number, 1000 episodes are simulated and your solution gets 1 point (2 points for 16 cards) if the average return is positive.

A template memory_game.py is available. Depending on memory_cells argument, it employs either a vanilla LSTM or LSTM with external memory. Note that I was able to train it only for 4, 6, and 8 cards.
